Pet Bottle Label Removing Plastic Flakes Washing Recycling Machine

接触

Pet Bottle Label Removing Plastic Flakes Washing Recycling Machine

最小注文数量 :	1	価格 :	$150,000.00/sets 1-1 sets
パッケージの詳細 :	標準輸出パッケージまたはカスタマイズされたパッケージ	受渡し時間 :	70営業日
供給の能力 :	30セット/セット/月ペット用プラスチックボトル洗浄リサイクルライン

起源の場所:	江蘇、中国	ブランド名:	MOOGE
証明:	CE	モデル番号:	MTシリーズ

詳細情報
アプリケーション:	PETボトルリサイクル	状態:	新しい
自動グレード:	自動	プラスチックタイプ:	ペット
生産能力（kg/h）:	500から5000	マシンタイプ:	ペットボトル洗浄ライン
装置のリスト:	脱水機,浮遊洗濯タンク,熱気乾燥機,摩擦洗濯機,ラベル分離機,ラベル除去機,熱洗濯タンク	max.production容量（kg/h）:	5000
電圧:	カスタマイズ	寸法（lwh）:	62m × 5m × 4.5m
パワー（kw）:	400	重量（t）:	20
保証:	12か月	キーセールスポイント:	生産性の高い
ビデオの発信検査:	提供された	適用産業:	プラスチック廃棄物リサイクル機械
ショールームの場所:	トルコイタリアベトナムブラジルメキシコタイアルゼンチンコロンビアウクライナ	機械テストレポート:	利用不可
マーケティングタイプ:	普通の製品	コアコンポーネントの保証:	1年
コアコンポーネント:	PLCの軸受け、変速機、モーター、ギヤ	色:	カスタマイズ
モーターブランド:	シメンズまたはカスタマイズ	速度制御:	インバーター制御
軸承のブランド:	HRB またはオーダーメイド	洗濯部品の材料:	ステンレス鋼または炭素鋼
人間の力:	6~10人	最終的なフラックの大きさ:	12〜14mm
蒸気使用:	オプション	加熱方法:	電気,蒸気,または源
水分含有量:	1％	保証サービスの後:	ビデオ技術サポート、オンラインサポート
ローカルサービスの場所:	エジプト,ベトナム,フィリピン,ペルー,パキスタン,インド,メキシコ,タイ,バングラデシュ,南アフリカ,キルギスタン	ポート:	上海の海港
ハイライト:	PET bottle label remover machine , plastic flakes washing recycling line , PET recycling machine with label removal

製品の説明

Product Overview

Waste Plastic Recycling Plant Scrap Pet Bottle Recycle Washing Line

This MT-series Waste Plastic Recycling Plant Scrap Pet Bottle Recycle Washing Line is mainly used to recycling the waste PET bottles, water bottles, cola bottles, PET sheet and PET packing containers, etc. The Waste Plastic Recycling Plant Scrap Pet Bottle Recycle Washing Line can easily remove the labels, caps, rings, glue, dirties and other impurities off from the pet plastic, finally we will get ideal PET flakes with good quality for reuse.

Product Specification

The Waste Plastic Recycling Plant Scrap Pet Bottle Recycle Washing Line we made with capacity from 500kg/h to 5000 kg/h.
We can design the machine layout into "L" or "U" shape according to buyer's actual factory area and requirements.

Model	Capacity	Installed Power	Steam Use	Water Supply	Manpower	Area Required
MT-500	500 kg/hr	190 KW	Optional	4-5 m3/hr	4-6 Person	6055 m
MT-1000	1000 kg/hr	260 KW	Optional	5-7 m3/hr	8-10 Person	8085 m
MT-2000	2000 kg/hr	400 KW	Suggest Use	10-15 m3/hr	10-12 Person	8085 m
MT-3000	3000 kg/hr	600 KW	80,000 Kcal	20-30 m3/hr	12-16 Person	100810 m
MT-4000	4000 kg/hr	800 KW	100,000 Kcal	30-40 m3/hr	15-20 Person	1351010 m
MT-5000	5000 kg/hr	1000 KW	120,000 Kcal	40-50 m3/hr	15-20 Person	1351010 m

We adopted well-known brand for the main motor, necessary parts of the machine.We manufacture the machine strictly according to the technical drawings and we can also make the components as buyer request

Item	Specification
Raw Material	Waste Rigid Plastic PET bottles, PET sheet, PET packages, etc
Finished Product	Clean dry plastic flakes (size can be recycled as buyer request)
Main Machine List	Bale Opener, Trommel, Label Remover Machine, Sorting Belt, Pre-washer Machine, Belt Conveyor, Crusher, Cold Washing Tank, High Speed Friction Washer, Hot Washing Tank, Centrifugal Dryer, Zig-zag Air Classifier, Color Sorter, Packing Silo
Machine Material	Machine frame is made by carbon steel, the machine washing part is made by SUS 304
Main Components	NSK/SKF bearing, TTO oil sealing, Guomao reducer,etc.
Electric Components	ABB/Delta inverter, Omron temperature meter, Schneider contactor, Chint switch, Siemens made in China motor, etc.
Warranty Period	One Year from the Machine Operation within 18 Months from the B/L Date
Turnkey After Service	Technical Support including the machine layout, electric diagram, working manual, engineer available to buyer's factory overseas for helping installation, commissioning, training workers, etc. consumable parts provided; 24-hours online after sale service;

Features At-A-Glance

Bale Opener Machine

Function: Open the pressed PET bales

>With 4 roller cylinder feeding the bottles equally, claw steel is very strong with 20mm thickness.

>Machine chamber made by solid strong steel, chamber size 1.6*1.6m (depth x width).
>We can make it with forklift working platform to push the bales, or with a hopper for temporary store the bales.

Label Remover Machine

Function:remove the labels from the bottles

>Blades made by tungsten carbide and are fixed by screw easy to adjust and replace

>The barrel designed with hydraulic system to lift up the chamber which is convenient to replace the blades

>The machine bottom with holes to drain out liquid which contained in the bottles, good for machine use

Plastic Crusher Machine

Function: crushing the PET bottles to small flakes.

>With water inlet doing the wet grinding which can extend the blades lifespan, reduce the dust generation.

>Crusher upper hopper opened by screw motor which save manpower

>Bearing house is installed outside of the crusher chamber so no dirty goes inside for longer use.

Floating Washing Tank

Function: with cold water washing out dirty from the flakes

>With the top rollers automatically take out the caps and rings and other impurities but with less water taken out

>Rotor shaft made by seamless steel tube.
>Screw is made by stainless steel, we have different model of floating washing tank according to your requirements.

Hot Washing Tank

Function: with hot water washing to remove oil/glue and other dirty from the flakes.
>The tank made with insulation layer to keep the hot water temperature and save energy.
>Feeding caustic soda or chemical detergent to washing the bottle flakes for better effect
>The water is heated up by steam, steam is generated by the steam boiler
